Cutting edge technology in high-speed marine crafts production
SEA BOATS PRODUCT LINE
JSC «VERF-77» was founded in 2020 by a group of specialists with more than a decade of experience in defense and security field supplying high-tech systems and providing operational readiness to Russian law enforcement agencies.
We are dedicated to creating and developing a leading-edge design and production process of high-speed marine crafts purpose built for protection of Russian maritime borders, anti-terrorist and rescue operations.
Our team has launched the production of three types of high-speed boats under the license from PT Lundin (Sweden, Indonesia).
VERF-77 has developed unique solutions for integration of Russian technology and weapon systems with PT Lundin's advanced boat designs. The project is underway, work schedules have been approved.
- G7 Fast interceptor with reinforced hull and closed cabin
- X18 Assault catamaran with 57 mm remote weapon system
- X19 High speed assault boat with missile weapons
- X3K Trimaran fast attack
The project for the joint production of modern high-speed boats was launched in 2018.
In December 2021, the final technical meeting was held in Moscow between representatives of JSC Verf 77 and PT Lundin, dedicated to the start of boat production in Russia.
The meeting was attended by managers and technical specialists from both companies.
During the meeting, final technical decisions were made regarding the integration of Russian equipment and armament into PT Lundin's boat projects. Work schedules and timelines were approved.
At present, the first batch of hulls for the G7 "Raskat" project has already been delivered to the Russian Federation, with the installation of Russian armament, navigation, communication, and control systems planned.
The X18 catamarans will be equipped with Russian weapons. А 57 mm remote weapon system or «Derivaciya PVO» 57 mm. Up to four 12.7 mm gun mounts for KORD MG. Automatic grenade launcher 40mm.
The lead prototype of the X19 project is currently under construction at the PT Lundin shipyard. Technical negotiations are underway regarding the integration of Russian missile armament onto the craft.
А 12.7 mm remote weapon system «Narval» or «Derivaciya PVO» 57 mm.
Anti ship missiles complex «Uran» or versatile guided missiles "305" (LMUR) or other weapon systems upon request from the customer.
The lead prototype of the X19 project is currently under construction at the PT Lundin shipyard. Technical negotiations are underway regarding the integration of Russian missile armament onto the craft.
А 12.7 mm remote weapon system «Narval» or «Derivaciya PVO» 57 mm.
Anti ship missiles complex «Uran» or versatile guided missiles "305" (LMUR) or other weapon systems upon request from the customer.
Latest news
-
Happy New Year 2026!We wish for our fruitful cooperation between PT Lundin and VERF 77 to gain new momentum and reach unprecedented heights in the coming year! May the most advanced and cutting-edge boats be laid down and successfully launched within the framework of our joint projects, embodying the strength of our alliance and our shared drive towards the future!
To new achievements and shared victories! -
Russia and Indonesia
Explore Creating Joint Shipbuilding ClusterVisit of Russian Maritime Board Head to Indonesia launches new phase of PT Lundin - Russia cooperation.Joint Russia–PT Lundin Projects
The recent visit of the Head of the Russian Maritime Board to Indonesia has marked a significant step in bilateral relations, paving the way for a new phase of joint projects with the Indonesian partner, PT Lundin.
-
Russia's Defense Industry newsTrimaran Golok commissioned into the Indonesian Navyvpk.name News
On January 14, 2022, the official commissioning ceremony for the all-composite missile trimaran Golok (hull number "688"), built at the Indonesian private company PT Lundin Industry Invest's shipyard in Banyuwangi, East Java, took place in Surabaya.
Indonesia Launches X18 Tank Boat Catamaran
Indonesia's state-owned defense conglomerate, PT Pindad (Persero), announced that a prototype of the X18 Tank Boat, a catamaran-hull armored vessel, was launched on April 28, 2021. The launch ceremony took place at the shipyard of PT Lundin Industry Invest in Banyuwangi, East Java.
G7
Fast interceptor "Raskat"
G7 Fast interceptor
ROLES
HULL
NAVIGATION AND COMMUNICATION
PARAMETERS
- Day or night visual, optic and radio reconnaissance, in clear or adverse weather conditions at substantial distance from the coast or a carrier ship
- Interception of enemy vessels, assault operations at sea, support during landings, patrol of internal waterways
- Fire support of landing forces, extraction of troops and injured
- Search and rescue at sea. Towing of vessels that have lost propulsion
- Patrol, protection, anti-terrorist and anti-sabotage missions
- High speed delivery of weapons and ammunition Interception of small high-speed craft. Anti-piracy missions
- Unmanned surface vehicles counteraction
HULL
- G7 offers the advantages of seaworthiness, stability and speed from an exceptional race proven triple stepped deep V hull. Created with vacuum infused carbon fiber, the hull is capable of withstanding structural impacts of more than 7G. G7 can be transported by air transport.
- Low visibility stealth profile and use of composite materials makes it difficult to detect G7 using modern radars
- Polyurethane fabric, D Shaped collar with seamless structure
- The deck provides space for several work stations, the non-skid surface guarantees secure footing even in the most challenging conditions
- Carbon fiber shock mitigation seats minimizing physical fatigue
- Cargo tracks allow for various seat configurations and equipment placement
- Towing points – one at the bow, two at transom; a total of four lifting points
- Cabin, doors and windows are protected with Class 4 (GOST-R 50744-95) armor plates (option when ordering)
- Collapsible foam filled fuel cells provide stability and fire protection
NAVIGATION AND COMMUNICATION
- High resolution doppler radar with CHIRP pulse compression. Inertial navigation system. Stabilized Electronic optics sensor. Multifunctional displays with sea charts installed. GPS/GLONASS receivers. AIS system. Digital depth, temperature and speed log sensors.
- VHF marine radio; combat radio with protected channels for battle coordination. Internal wireless protected communication system with GPS module. Intercom, ethernet, IP and Wi-Fi access.
PARAMETERS
Length, m | 11,80 |
Beam, m (inflated collar) | 2,85 |
Draught, m | 0,80 |
Displacement, kg | 3100 |
Range, NM | 250 |
Maximum sea state | 3 |
Propulsion | 3 х Mercury Vеrаdо 450R |
Maximum speed, knots | 70 + |
Cruising speed, knots | 55 |
Crew, persons | 4+6 |
WEAPON SYSTEMS
12.7 mm remote weapon system «NARVAL»
Option 1
12.7 mm remote weapon system «NARVAL» - 1 pcs.
12,7 or 7,62 mm MG with optic systems – 2 pcs.
12.7 mm remote weapon system «NARVAL» - 1 pcs.
12,7 or 7,62 mm MG with optic systems – 2 pcs.
Option 2
- 12.7 mm remote weapon system «NARVAL» - 2 pcs.
Option 3
- 12,7 or 7,62 mm MG with optic systems – 2 pcs.
- GSHG MG – 1 pcs.
Option 4
- 12,7 or 7,62 mm MG with optic systems – 2 pcs.
- Compact portable assault station «Lancet» FH-901/FH-901А – 10 pcs.
UNMANNED SURFACE VEHICLES COUNTERACTION
G7 is a high-speed versatile interceptor boat, a very important missing link in the lineup of small displacement battle ships. Having considerable firepower this boat can act on its own in interception, boarding, USV elimination and reconnaissance missions delivering swift and unpredictable strikes.
FEATURES
The G7 offers the advantages of seaworthiness, stability and speed from an exceptional race proven triple stepped hull. The longer than average length enables it to maintain higher speeds in rough conditions, making it ideal for insertion of Special Forces, high-speed pursuits, and boarding operations. These features also make it well suited for pursuit and law enforcement roles.
- Low visibility profile on radar
- High speed, mobility and maneuverability
- Sea, coastal waters or river deployment
- Boarding operations capability
- Precise firing on various targets close range and at long distances, in any weather conditions, day or night
- Covert transport and storage inside a standard sea transport container.
The G7 offers the advantages of seaworthiness, stability and speed from an exceptional race proven triple stepped hull. The longer than average length enables it to maintain higher speeds in rough conditions, making it ideal for insertion of Special Forces, high-speed pursuits, and boarding operations. These features also make it well suited for pursuit and law enforcement roles.
X18
Assault catamaran
X18 Assault catamaran
ROLES
TECHNICAL SPECIFICATIONS
WEAPON SYSTEMS
HULL
- Maritime military operations
- Engagement of single or multiple surface, land or air targets
- Overwatch during landing on an unprepared coast
- Search missions at sea
- Electro-optical and radio reconnaissance at sea and in coastal waters
- Landing armed troops with weapons and equipment
- Fast delivery of ammunition and support cargo
- Evacuation of troops
- SAR operations
- Air defense boat capability
- Versatile carrier platform for maritime air/surface unmanned vehicles and FPV
TECHNICAL SPECIFICATIONS
Length, m | 18,97 |
Beam, m | 7,50 |
Draught, m | 0,9 |
Displacement, t | 43 |
Range, NM | 600 |
Maximum speed, knots | 50 |
Cruising speed, knots | 40 |
Maximum sea state | 4 |
Autonomy, days | 2 |
Main engine | 2х1700 diesel MAN |
Propulsion | 2 waterjets |
Crew, persons | 4 |
Operators, persons | 48 |
WEAPON SYSTEMS
- 57 mm remote weapon system or «Derivaciya PVO» 57 mm.
- Up to four 12.7 mm gun mounts for KORD MG.
- Automatic grenade launcher 40mm.
HULL
- X18 catamaran is a double hull high-speed maneuverable boat built using stealth technology. Hull design enables the use of heavy weapon systems. Cabin, doors and windows are protected with composite armor. The boat has a low visibility profile and the added advantage of shallow draft, giving it the ability to execute beach and river landings and insert or extract squads in shallow waters.
- Built with multilayered multidirectional carbon fiber composite with corecell foam core fused using vacuum infusion technology.
- The deck is covered in non-skid material. Boat color is chosen according to the customer's requirements.
- Cargo tracks on the deck and boat sides provide for custom seat configurations and cargo placement.
- Two towing points at the bow and high load towing point at transom. Aft deck can carry up to five tons of equipment and drones.
- Shock mitigating carbon fiber seats for crew and operators.
AU-220M WEAPON SYSTEM TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rate of fire, shots/min | 120 |
Range, km,: maximum maritime targets air targets land targets | 12,0 9,5 6,0 9,5 |
Horizontal/vertical aiming angles, degrees | ±120/ -5 ..+75 |
Aiming speed VN /GN/ target switch, degree/sec | 40/60/80 |
Ammunition, pcs. | 100 |
Ammunition reserve, pcs. | up to 500 (5 ammo kits) |
Target detection range, km: surface target similar to BK-16 airplane UAV light armor land vehicles armored personnel carrier | 10 15 6 6 |
Dimensions, mm: length width height | 5730 (3750) 3400 2950 (2550) |
Projectile type | Fragmentation Tracer Round | Multifunctional with a remote-contact fuse | Armor-piercing sub-caliber |
Target type | Maritime, enemy manpower | Maritime, air, enemy manpower | armored personnel carrier, protected air targets |
FEATURES
X18 is a high-performance versatile boat, it combines surveillance, protection, and support at a reasonable cost.
It is a necessary addition to the existing surface fleet of small displacement boats.
Combining high-speed, substantial firepower with high load and troop capacity,
X18 is ideally suited for amphibious deployment of commandos and assault missions, it can serve as a versatile carrier boat for sea and air unmanned vehicles and FPVs.
- Target engagement range is 2,5 times higher than that of potential enemy boats of similar displacement
- Concentrated fire on all types of targets in any weather conditions, day or night
- High rate of fire, increased aim precision while moving
- Suited for use at sea and on rivers
- Versatility
- Low visibility
- Mobility and maneuverability
- High stability while firing
- Landing missions capability
- Precise covering fire and support during landing
X18 is a high-performance versatile boat, it combines surveillance, protection, and support at a reasonable cost.
It is a necessary addition to the existing surface fleet of small displacement boats.
Combining high-speed, substantial firepower with high load and troop capacity,
X18 is ideally suited for amphibious deployment of commandos and assault missions, it can serve as a versatile carrier boat for sea and air unmanned vehicles and FPVs.
X19
High speed assault boat
X19 High speed assault boat
ROLES
TECHNICAL SPECIFICATIONS
WEAPON SYSTEMS
- Blue water missions at significant distance from the coast
- High-speed interception and elimination of targets
- Landing area reconnaissance using modern electro-optical and radio systems
- Provision of fire support to boarding boats
- Covert insertion and extraction of commandos groups
TECHNICAL SPECIFICATIONS
Length, m | 20 |
Beam , m | 4,6 |
Height , m | 4 |
Draught, m | 1,2 |
Displacement, t | 33 |
Maximum speed, knots | 50+ |
Cruising speed, knots | 35 |
Main engine, h.p. | 2 x 2000 MAN VI2-2000, at 2300 RPM |
Propulsion | 2 х waterjet KONGSBERG KAMEWA S-40-3 /СА |
Electric generators, kWt | 2х11 |
Fuel capacity, litre | 5000 |
Fresh water capacity, litre | 600 |
Range, NM at 30 knots at 9 knots | 330 600 |
Crew, persons | 6+8 (crew + operators) |
WEAPON SYSTEMS
- 12.7 mm remote weapon system «Narval» or «Derivaciya PVO» 57 mm.
- Anti ship missiles complex «Uran» or versatile guided missiles "305" (LMUR)
- or other weapon systems upon request from the customer.
HULL
FEATURES
X19 is a high-speed assault boat is designed for patrol and interception roles in blue water and coastal areas. X19's impressive firepower, excellent sea keeping and state of the art electro-optical equipment enable it to strike unexpectedly and quickly, proving a highly effective, versatile and effective combat unit that is a necessary addition to the existing surface fleet.
The use of small missile boats in addition to traditional military ships allows commanders to push the boundaries of combat ability by improving readiness and mobility, enabling shallow water operations while maintaining significant firepower.
- Built with multilayered multidirectional carbon fiber composite with corecell foam core fused using vacuum infusion technology.
- Has a low radar profile.
- Capable of high-speed maneuvering in adverse weather conditions.
FEATURES
- Low radar visibility (low profile, 90% composite meterial, carbon structure).
- High maneuverability with waterjets.
- High speed (up to 55 knots, cruising at 35 knots).
- Operates at sea states of up to 4
- Customizable internal space (can carry divers, reconaissance or assault groups), up to a maximum of 8 persons.
- Optional gun posts (12,7 and 7,62 mm), including UAV or non-lethal systems.
- Modern electro-optical and radio reconnaissance equipment allows for operation in any weather and visibility conditions during the day and at night.
- Add-on composite armor plates can be installed around the engine and boat perimeter
X19 is a high-speed assault boat is designed for patrol and interception roles in blue water and coastal areas. X19's impressive firepower, excellent sea keeping and state of the art electro-optical equipment enable it to strike unexpectedly and quickly, proving a highly effective, versatile and effective combat unit that is a necessary addition to the existing surface fleet.
The use of small missile boats in addition to traditional military ships allows commanders to push the boundaries of combat ability by improving readiness and mobility, enabling shallow water operations while maintaining significant firepower.
X3K
Trimaran fast attack
X3K Trimaran fast attack
DESCRIPTION
The Fast Attack Craft (FAC) employs a modern “Wave Piercing” trimaran design. This allows the vessel to cut-through waves rather than rise up and over them, and the increased beam provides inherent stability. This combination of features reduces both pitching and rolling, creating a stable weapons platform, and enabling the vessel to comfortably and safely maintain higher average speeds in adverse conditions.
The FAC has “Stealth” design characteristics, and incorporate features that minimise detection by reducing Radar, Infra-Red, Acoustic and Magnetic signatures. Stealth properties are further improved as there are no reverse-angle bow overhangs to reflect radar signals, as seen on conventional hull forms. Weaponry, including missiles and naval guns, and the ships 11 m high-speed RIB, are discreetly concealed or shaped to meld into the superstructure profile.
The wide decks on the 63m FAC Trimaran also make it an ideal platform for carrying a helicopter, which extends the effective patrol range and capabilities of the vessel.
TECHNICAL SPECIFICATIONS
The Fast Attack Craft (FAC) employs a modern “Wave Piercing” trimaran design. This allows the vessel to cut-through waves rather than rise up and over them, and the increased beam provides inherent stability. This combination of features reduces both pitching and rolling, creating a stable weapons platform, and enabling the vessel to comfortably and safely maintain higher average speeds in adverse conditions.
The FAC has “Stealth” design characteristics, and incorporate features that minimise detection by reducing Radar, Infra-Red, Acoustic and Magnetic signatures. Stealth properties are further improved as there are no reverse-angle bow overhangs to reflect radar signals, as seen on conventional hull forms. Weaponry, including missiles and naval guns, and the ships 11 m high-speed RIB, are discreetly concealed or shaped to meld into the superstructure profile.
The wide decks on the 63m FAC Trimaran also make it an ideal platform for carrying a helicopter, which extends the effective patrol range and capabilities of the vessel.
TECHNICAL SPECIFICATIONS
Length Over All | 63 m |
Beam Over All | 16 m |
Draught | 1.2 m |
Displacement | 230 t |
Speed (Max Power) | 30 knots + |
Speed (Cruising) | 16 knots |
Propulsion |
|
Main Engines : | 4 x 1800 HP MAN V12 |
Gearbox : | 4 x single input/output |
Waterjets : | 4 x MJP 550 |
Fuel Capacity | 50,000 l |
Fresh water | 5,000 l |
Range | 2000 Nm at 16 knots |
Crew | 29 Persons |
STANDARD FEATURES
General
General
- Hull Material : Carbon Fibre Foam Sandwich, Resin infused used osmosis resistant, fire resistant vinyl ester resin.
- Main Engines : 4 x 1800 HP MAN V12
- Gearbox : 4 x single input/output
- Waterjets : 4 x MJP 550
- 7,200 horsepower (5.4 MW)
- Radar, GPS, AIS, Log, MET system
- Generator sets : 3 x 135 kW 380/220V 60 Hz
- STANDARD FEATURES
- Fire Extinguisher : Hand operate fire extinguisher, Coldcut COBRA water mist extinguisher system,
- Fixed FI-FI CO2 system in engine compartments
- Rescue Equipment : Life jackets, Life Buoys, Life Raffs
- Main Armament : Up to 40mm Naval Gun
- Secondary : 2 x 12.7mm Gun
- Boat : 1 x 11 mm high-speed RIB
ADVANTAGES
X3K Trimaran has a length of 62.53 meters, a width of 16 meters, a draft of 18.7 meters, a weight of 53.1 tons. A maximum speed of 28 knots and a cruising speed of 16 knots. The vessel was powered by four MAN V12 diesel engines with total power output of 7,200 horsepower (5.4 MW), which propelled four MJP 550 waterjets, with two located on the outrigger and the other two on the main hull. X3K has a maximum speed of 35 knots (65 km/h), with cruising speed at 22 knots (41 km/h).
She has a range of around 2,000 nautical miles (3,700 km) at 16 knots (30 km/h). The vessel has a complement of 29 personnel, including a team of special forces. X3K was planned to be armed with four and up to eight C-705 anti-ship missiles in enclosed launchers and a Type 730 CIWS in stealthy turret.
The vessel also able to be armed with Penguin or Exocet missiles and naval gun of up to 57 mm caliber without affecting the stability of the vessel. She also carried an 11 m high-speed rigid-hulled inflatable boat for the special forces team.
X3K Trimaran has a length of 62.53 meters, a width of 16 meters, a draft of 18.7 meters, a weight of 53.1 tons. A maximum speed of 28 knots and a cruising speed of 16 knots. The vessel was powered by four MAN V12 diesel engines with total power output of 7,200 horsepower (5.4 MW), which propelled four MJP 550 waterjets, with two located on the outrigger and the other two on the main hull. X3K has a maximum speed of 35 knots (65 km/h), with cruising speed at 22 knots (41 km/h).
She has a range of around 2,000 nautical miles (3,700 km) at 16 knots (30 km/h). The vessel has a complement of 29 personnel, including a team of special forces. X3K was planned to be armed with four and up to eight C-705 anti-ship missiles in enclosed launchers and a Type 730 CIWS in stealthy turret.
The vessel also able to be armed with Penguin or Exocet missiles and naval gun of up to 57 mm caliber without affecting the stability of the vessel. She also carried an 11 m high-speed rigid-hulled inflatable boat for the special forces team.
JSC "VERF 77" SPECIALIZED SOLUTIONS AND TECHNOLOGIES
JSC "VERF 77" is a Russian developer of high-speed boats
constructed from high-strength carbon-fiber reinforced polymer.
constructed from high-strength carbon-fiber reinforced polymer.
KEY STRENGTHS
INNOVATION
Each boat is a unique product created with specific end use in mind, developed in close contact with the client according to their mission goals.
CUSTOM SOLUTIONS
Using modern production equipment and latest software, our team of highly skilled engineers and experts focus on delivering a custom solution tailored to the client’s mission requirements.
COOPERATION
A large network of Russian and international partners specializing in boat equipment production enables us to cooperate with hundreds of manufacturers to make sure each part of the boat meets high quality requirements.
EFFICIENCY
A modern, environmentally friendly assembly facility ensures high quality and on-time delivery. We ensure operational reliability throughout the entire life cycle.
INNOVATION
Each boat is a unique product created with specific end use in mind, developed in close contact with the client according to their mission goals.
CUSTOM SOLUTIONS
Using modern production equipment and latest software, our team of highly skilled engineers and experts focus on delivering a custom solution tailored to the client’s mission requirements.
COOPERATION
A large network of Russian and international partners specializing in boat equipment production enables us to cooperate with hundreds of manufacturers to make sure each part of the boat meets high quality requirements.
EFFICIENCY
A modern, environmentally friendly assembly facility ensures high quality and on-time delivery. We ensure operational reliability throughout the entire life cycle.
7 (495) 925-14-29
E-mail: info@ptlundin.ru
www.ptlundin.ru
E-mail: info@ptlundin.ru
www.ptlundin.ru
